Specifications:
Panel size max: 620x620mm
Panel thickness (incl. Cu): 0.3mm-7.0mm
Line width/space: 2mil/2mil
Aspect ratio through hole: 15:1
Aspect ratio blind hole: 2:1
Etching capability
uniformity 93%
etching factor >4
Flexible for alkaline-base or organic-base stripper system
Unbalance copper thickness board 1:2 1:3

Specified by Customer:
Working height, width & direction
Line speed
Conveyor type, etc.
